TEMPORIS IP Extension Module for ALCATEL Temporis IP800
- Ideal for administrative assistants, receptionists and workers who have to monitor, manage and cover call status.
- Make it your own. Configure the keys to meet your specific needs: BLF, BLA, XML browser, line or speed dial keys and many more.
- Benefit from a large graphic display with easy-to-understand icons and dual color LED keys to know line status at a glance.
- Install it to suit you thanks to the adjustable 2-position foot stand.
An intuitive tool to enhance call handling
- Large graphic display
- Dual color LED keys
- Up to 38 functions keys
- 6 Temporis IP Extension Modules can be daisy chained
Main features
- 160x320 graphic display with 4-level gray scales
- LCD icons dedicated to each programmed function
- Dual color LED for status information
- Supports Busy Lamp Field (BLF), Bridge Line Appearance (BLA), speed
dial, call pick up, intercom, call park, directory (local or network), LDAP,
XML browser , voicemail, call forward, DND…
Key pad
- 20 physical keys
- Up to 38 keys thanks to page switch function
- Dual color LED buttons (green/orange)
Interfaces
- 2 RJ-12 ports (data in and out)
Supported phones
- Temporis IP800
Physical & Environmental
Mounting:
- Adjustable footstand: 2 positions
Power Supply:
- Temporis IP Extension Module is powered directly by Temporis IP800 for up to two daisy-chained modules.
- When more than 2 extension modules (up to 6) are required a power adaptor is needed.
Power Adaptor: not provided
- Input: AC 100/240V
- Output: 5V/3A
Dimensions:
- 192x120x45mm (HxLxD)
Operating temperature:
- From 0° to 40°C
Storage temperature:
- Up to 60° C
Humidity:
- Up to 90% non-condensing
