Elevated Design & Experience
The Alta Labs AP6 Access Point features a compact form factor and a sleek aesthetic design allowing seamless integration into corporate, commercial, and residential environments. The AP is powered over Ethernet for simple, clean installation. Versatile mounting hardware is included featuring our proprietary QuickMount™ technology for quick, simple mounting.
Superior Range and Performance
Our proprietary antenna design provides superior range and performance. Engineered by a team with extensive WiFi design expertise, the AP6 provides seamless roaming and advanced traffic management to ensure a superior WiFi experience.
Features
• Superior Range and Performance
• Scalable Cloud-Based Management
• Mobile App
• High Performance WiFi 6
• Multi-Password Authentication
• DPI Engine
• Hotspot Functionality
• On-The-Fly Changes and Scanning
• Wireless Network Color Coding
• SSID Broadcasting Flexibility
• Customizable Dashboard
• Status Snapshots
• Device Cards
Scalable Cloud-Based Management
Alta Labs provides an intuitive and easy-to-use cloud-based management interface for Alta Labs access points and switches. Designed for optimum scalability using a high-availability architecture for the ultimate in convenience and worldwide accessibility. Built on a worldwide content delivery network to optimize response and latency, our global cloud infrastructure ensures geographically optimized connectivity through our redundant network. Deploy and manage multiple sites quickly and easily. Add, delete, or rename sites instantly. Toggle between sites from a site selection drop-down. Each site contains its own data set.
High Performance WiFi 6
Built on Qualcomm's dual-band, 4-stream WiFi 6 networking platform, the AP6 delivers optimal 2.4 GHz and 5 GHz WiFi 6 performance.
Multi-Password Authentication
Use different WiFi passwords to separate network traffic and manage connectivity.
- Standard Network with less than 100 WiFi clients
- Large Optimized for hundreds to thousands of WiFi clients
- IoT Restricted to Internet and local incoming connections only
- Internet Restricted to Internet only
- Guest Restricted to Internet and IoT devices A password can also be associated with a specific upload or download rate, a VLAN, or to bypass schedule or hotspot functionality.
Mobile App
Monitor and manage your networks from the convenience of your mobile device. The management interface is easily accessible via mobile app or web browser. Sign up for an Alta Labs account using just your name, email, and password or use Google Authentication.
DPI Engine
Advanced filtering allows you to block content by application, selectable from an extensive predefined list. You can also enter domain names for domain blocking.
Hotspot Functionality
Built-in functionality to create your own local hotspot with a logo, title page, terms of service, and a final landing page. You also have the option to redirect to an external URL.
Wireless Network Color Coding
Patent pending functionality that allows you to assign groups to wireless SSIDs and then assign membership to wireless access points.
SSID Broadcasting Flexibility
In addition to standard functionality such as hiding your SSID, you can continue broadcasting your SSID during a “scheduled off” event. This provides network admins with the ability to grant users additional time on the network. A user can request access via a captive portal displayed when they try to access the network.
Customizable Dashboard
Customize your dashboard with the information you want to see: IP address, Load, number of devices, MAC address, firmware version, wireless network color assignment, and real-time status details. Details are sortable by column.
Status Snapshots
View upload and download throughput with a visual timeline on the dashboard for each AP displayed along with the number of connected devices, average processor load, channel load, and average connected devices. Select a snapshot of the last minute, last hour, last two days, or last two months.
Device Cards
Easily view connection details and configure your access points or client connections by clicking the device icon.
SPECIFICATIONS
MECHANICAL
Dimensions: 190 x 125 x 32 mm (7.5 x 4.9 x 1.25")
Weight: 0.4 kg (0.9 lbs)
Enclosure Material: Top Cover: Polycarbonate, Bottom Cover: Milled Aluminum
Mount Material: Ceiling/Wall: Polycarbonate, Drop Ceiling: Steel
HARDWARE
Network Interface: Ethernet, WiFi, Bluetooth
Management Interface: (1) GbE RJ45 Port
Button(s): Reset/Factory Reset
LED: Blue, White
Power Method: PoE+ (PoE-In)
Power Supply: PoE+ Enabled Network Switch or 48V, 0.5A PoE Adapter (Optional)
Supported Voltage Range: 42.5-57V DC
Max. Power Consumption: 20W
Max. Transmit Power: 2.4 GHz: 23 dBm @2NSS, 5 GHz: 23 dBm @2NSS
MIMO:
5 GHz: 2 x 2, DL MU-MIMO, DL/UL MU-OFDMA
2.4 GHz: 2 x 2, DL/UL MU-OFDMA
Explicit TX beam-forming
Throughput Rate: 2.4 GHz: Up to 573 Mbps, 5 GHz: Up to 2.4 Gbps
Antenna Gain: 2.4 GHz: Up to 4.0 dBi, 5 GHz: Up to 4.1 dBi
Mounting: Wall, ceiling, drop-ceiling, table top
Operating Temperature: -30 to 60° C (-22 to 140° F)
Operating Humidity: 5 to 95% Noncondensing
Certifications: CE, FCC, IC (Visit Alta.inc for a full list of certifications)
