Dock mobile phone or PAD, support IOS or Android; 128*64 graphic LCD, Built-in HD voice engine; Provide two operate mode: touch screen and old keypad to meet different habits; EP+ in the mobile phone can be used to command U7KS to make a call; 3*SIP accounts,15*Programmable keys,2*Gigabit ports,2*USB ,RJ9 Headset,adjustable bracket,HD Codec, HD speaker, HD handset, Electronic hock,Built-in POE and Blue tooth,EHS, advance Mobile Phone Line allow the U7KS to answer or make a mobile phone call, use UniWIFI dongle for uplink, provide SDK for third-party APP,up to 5000 entries phone book.
- 2.4" 128x64-pixel display with backlight
- 3 multi-functional line keys, up to 15 Paperless DSS Keys
- Support EP + (Android/
iPhone iOS APP) - Optima HD voice, Full-duplex speakerphone
- Dual-port Gigabit Ethernet, integrated POE
- 2xBuilt-in USB Port, U7KS support USB WIFI Dongle and USB Bluetooth Dongle
- Up to 3 SIP accounts, 3-way conferencing
- Integrated stand with multi adjustable angles
- The Perfect IP Phone For Office
EP+ APP (Android/Apple iPhone - iOS)
EP+ is a Cell Phone communication assistant software to enhance IP phone Features. Cell Phone controls IP Phone to call / answer, Synchronizing ringing, Switch talking, etc. With the EP+, the IP Phone is integrated with Cell Phone, you can take the IP Phone to everyhere. You can switch talking between IP Phone and Cell Phone. So you can dial by Cell Phone and talk by the IP Phone.
Features
- EP+ controls IP Phone to make a call (Fast search contacts in the phone and speedy dial) .
- EP+ synchronizes the IP Phone’s phonebook to Cell Phone.
- EP+ and IP Phone can switch talking freely;
- Mobile Extension.
- EP+ and IP Phone ring at the same time during incoming call, you can answer the call by either one.
Note: It should be used for the models above iPhone5s with systems above IOS6 and all Android Phones with systems above Android4.4. Audio codes: G.711A/U, G.729, iLBC.
Phone Features
>3 SIP accounts, Hotline
>Call hold, Call waiting, Call forward, Call return
>Call transfer (blind/busy/ask)
>Caller ID display, Redial, Mute, DND
>Auto-answer, 3-way conferencing
>Speed dial, SMS, Voicemail Message Waiting Indication LED
>Tone scheme, Volume control
>Direct IP call without SIP proxy
>Ring tone selection/import/delete
>Black list, Hand-free indicator.
>Call history: dialed/received/missed;
>Multi-Language
>Soft keys programmable, Supports PC control
Advanced Features
>XML Phone Book search and input & output
>Enterprise phone book
>LDAP phone book
>Functions customizable keys
>Support up to 30 paperless DSS keys
IP PBX System Integration
>Busy lamp field (BLF), BLF list
>Bridged line appearance (BLA)
>DND & Forward synchronization
>Intercom, Paging, Music on hold
>Call pickup, Dial Plan, Call recording Anonymous call, Anonymous call rejection
>Network conference, Distinctive ringtone
Codes and Voice Features
>Wideband Codec: G.722
>Narrowband codec: G.711µ/A, G.723.1
>G.726, G.729AB,iLBC
>VAD, CNG, AEC, AGC
>Full-duplex,
Security
>LLDP, VLAN QoS (802.1pq),VPN(L2TP)
>Transport Layer Security (TLS)
>Digest authentication using MD5/MD5-sess
>Secure configuration file via AES encryption
>Phone lock for personal privacy protection
>Admin/User 2-level configuration mode
Network Features
>SIP v1 (RFC2543), v2 (RFC3261)
>DNS SRV (RFC3263)
>NAT Traversal: STUN mode
>DTMF: In-Band, RFC2833, SIP Info, Auto
>HTTP/HTTPS Web Management
>IP Assignment: Static/DHCP/PPPoE Bridge/Router mode for PC port>TFTP/DHCP/PPPoE client
>DNS client, NAT/DHCP server
Management
>Auto-provision via FTP/TFTP/HTTP/HTTPS
>SNMP V1/2 , TR069 optional
>Configuration: browser/phone/auto-provision
>Trace package and system log export
Physical Features
>128x64-pixel display with blacklight
>36 keys, 6 LED lights,
>1xRJ-9 handset port
>1xRJ-9 headset port
>1xRJ-11 PSTN port
>2xRJ45 10/100/1000M Ethernet ports
>Power adapter: AC 100~240V input and DC 12V/1A output
>2x USB port
>Power over Ethernet ,IEEE 802.3af,class 0
>Power consumption: 2.5-3.5W
>Net weight:
>Dimension:
>Operating humidity: 10~95%
>Storage temperature: up to 60°C
