OpenVox VS-GW1202 V2 FXS/FXO Analog Gateway
4 cores intel CPU inside // Support up to 16 FXS/FXO channels // Up to 16 concurrent calls with transcoding and EC.
Specifications
VS-GW1202 V2 Analog Gateway, an upgrade product of the VS-GW1202 Series, is now the leading open source Asterisk-based VoIP Gateway solution for SMBs and SOHOs. With a friendly GUI and unique modular design, users may easily setup their customized Gateway. Also, secondary development can be completed through AMI (Asterisk Management Interface).
There are three models with a new VoxStack series Gateway, VS-GW1202 V2, VS-GW1600 V2 and VS-GW2120 V2 Analog Gateway. The VS-GW1202 V2 Analog Gateway can support up to 16 FXS/FXO channels and concurrency under full load which means 16 channels can be used for simultaneous calls. Besides, it can also support up to 16 concurrent calls with transcoding and EC synchronously. The Modular Design Analog Gateways are developed for interconnecting a wide selection of codecs, including G.711A, G.711U, G.729, G.722, G.723, G.726 & ILBC, to quickly reduce telecommunication expenses and maximize cost-savings. The Analog gateway designs with a Lan Switch board that provides stackability on the hardware upgrade.
The VS-GW1202 V2 Analog Gateway use standard SIP protocol and compatible with Leading IMS/NGN platform, IPPBX and SIP servers, support most of the VoIP operating platforms such as Asterisk, Elastix, 3CX, FreeSWITCH, Broadsoft, etc.
Technical Specifications:
- 8/16 FXS/FXO ports
- CPU: 4 cores, 1.33GHz
- Built-in fan
- RAM:1G
- Network ports:1
- USB port:1
- Serial port:1
- Reset Button:1
- Storage temperature range: -20~70°
- Operation temperature range: 0~40°
- Operation humidity range: 10%~90% non-condensing
- Power source: 12V DC/2A
- Max Power Consumption: 24W
- Dimension: 15cm × 19cm × 4.5cm
- Weight: 1110g
Software & Platform:
Features
- Simple and convenient configuration via Web GUI
- Abundant Log Features
- Open API interface(AMI)
- Support T.38 fax relay and T.30 fax transparent,can continually fax multiple pages
- Echo cancellation and Static jitter buffer
- Support DTMF relay
- Support Ring cadence and frequency setting
- Support volume control
- Support MWI(Message waiting indicator)
- Support DHCP?DNS/DDNS?NAT networking
- Support diverse SIP protocols
- Diverse extensible applications, such as IVR,DISA
- Support NTP time synchronization and client time synchronization
- Support modify username and password for web login
- Support SSH remote operation
- Support SRTP
- Support SIP server mode
- Support update firmware online
- Support configuration file backup and upload
- Support for custom scripts, dialplans
- Support restore the factory settings
- Affordable Price with Superior Performance
- Hot-swap Design for Modules
- Compatible with Asterisk, Elastix, 3CX, FreeSWITCH Sip Server and VOS VoIP operating platform
Accessories
- VS-GWM820-O
Each module offers 8 FXO ports.
- VS-GWM820-S
Each module offers 8 FXS ports.
- VS-GWM820-O/S
Each module offers 4 FXO ports and 4 FXS ports.
- VS-GWM820 Control Board
Control board with intel Quad Core processors.
Demo
- Online Demo (http://demo.openvox.cn:65322)
- Username:admin
- Password:admin
